INDFOS MP-1
₹1,052.00 (excl. GST 18%)
Application/Type
Refrigeration Gasses
Enclosure (Housing) Type
Weather Proof
On/Off Differential Type
Adjustable
Sensor Type
Bellow
Sensor Material
Phosphor Bronze Bellow
Micro Switch
1x SPDT (1 NO + 1 NC)
Micro Switch Rating
AC Rating: 10A 230 V AC
Process Connection
1/4″ Flare Nut
Pressure Range
(-) 0.4 to 7 Bar
HSN CODE: 90322010
Disclaimer: Representative image. Actual product may vary based on exact model number.
10 in stock
Description
1. Switch Type : Pressure
2. Service : Refrigeration Gasses
3. Reset : Auto
4. Sensor Type : Bellow Copper Alloy
5. Wetted Parts : Free Cutting Steel , Tin Plated
6. Enclosure : IP:33
7. Setting Range : (-) 0.4 to 7 Bar
8. Permissible Switch Point on Rising Pressure : 0.2 to 7 Bar
9. Adjustable Switch Differential : 0.6 to 6 Bar
10. Max Working Pressure : 16 Bar
11. Process Connection : 1/4″” Flare with Nut
12. Micro Switch : 1x SPDT
13. Electrical Rating : AC-1: 10A, 230V
14. Electrical Entry : Rubber grommet for cables 6 to 14mm
15. Process Temperature : (-) 20 to 70 Deg C
Additional information
| Application | 1. Refrigeration Compressors 2. Chillers 3. Driers 4. HVAC |
|---|
