WIKA Pressure Gauge : Body: SS with Brass Internals , Dial Size: 100mm , Range: 0 – 1000 KG/CM²

Alias: WIKA 213.53.100.Bottom (1000 KG)

2,192.00 (excl. GST 18%)

WIKA SS Body Brass Internals Pressure Guage 4″ Dial ; Range: 0 to 1000 KG/CM² ; 1/2″ BSP Bottom Connection

Body Material (Casing)

SS Body Brass Internals

Internals (Measuring System)

Copper Alloy

Filing

Glycerine

Entry Type

Bottom Connection

Dial Size

4″ (100 mm)

Range

0 – 1000 KG/CM²

HSN Code – 90262000

10 in stock

Description

1. Dial (Nominal) Size : 100 mm
2. Range : 0 to 1000 KG/CM²
3. Connection : 1/2″ BSP Bottom Connection
4. Measuring System : Copper alloy
5. Case : SS with Case vent
6. Accuracy : 1% of FS
7. Filling : Glycerin
8. Movement : Copper alloy
9. Window : Clear Plastic
10. Dial : White Aluminium
11. Pointer : Black Aluminium
12. Front Flange : No
