SWITZER DM-601-B26-S1-3-A

Alias: SWITZER DM-601-A-S1-3-A

3,215.00 (excl. GST 18%)

SWITZER Diaphragm Type Pressure Switch With Weather Proof Enclosure
SWITZER DM 601 B26 S1 3A

Application/Type

Pressure Switch

Enclosure (Housing) Type

Weather Proof

On/Off Differential Type

Fixed

Sensor Type

Diaphragm

Sensor Material Micro Switch

SS 316

Micro Switch

1x SPDT (1 NO + 1 NC)

Micro Switch Rating

AC Rating: 15A 250 V AC

Process Connection

1/4″ NPT (F)

Pressure Range

0.2 to 1.6 Bar

HSN Code: 90322010
Disclaimer: Representative image. Actual product may vary based on exact model number.

5 in stock

Already sold: 3

Description

1. Switch Type : Pressure
2. Sensor Type : SS 316 L Diaphragm
3. Wetted Parts : SS 316
4. Enclosure : Aluminium Pressure Die Cast Weatherproof To Ip:66
5. On/Off Differential : Fixed Within 6 – 10% Of F.S.R.
6. Range : 0.2 to 1.6 Bar
7. Maximum Working Pressure : 60 Bar
8. Process Connection : 1/4″” NPT (F)
9. Micro Switch : 1x SPDT (1 NO + 1 NC)
10. Micro Switch Rating : AC Rating — 15A, 250V / DC Rating — Resistive : 0.5A 110V / 0.25A 220V / 8A 24V
11. Electrical Entry : 1/2″” NPT (F)
12. Maximum Fluid Temperature : 170 Deg C

Alias: SWITZER DM-601-A-S1-3-A

Additional information

Application

1. Hydraulics 2. Pneumatics 3. Fire Fighting 4. Pumps Control 5. Compressors Control 6. Power 7. Special Purpose Machines
